500L/H 1000L/H Fiberglass Stainless Steel Water Treatment Plant Ro System

MOQ

$190-$1422 usd/set

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Name: RO Water Treatment

Processing Type: Reverse Osmosis System

Certifications: Rohs,CE

Additional Features: Automatic Shut-off, Leak Protection, Quick Connect Fittings

Filtration System: Reverse Osmosis

Capacity: 2000L/H,50GPD,1500L,500LPH,10L-50

Condition: New

Highlight:

fiberglass RO water treatment system

stainless steel RO system 1000L/H

500L/H water treatment plant with warranty

Basic Infomation

Place of Origin: China

Certification: CE,Rosh

Document: Product Brochure - Sichuan ...me.pdf

Payment & Shipping Terms

Payment Terms: L/C,D/A,T/T,D/P,Western Union

Gallery

500L/H 1000L/H Fiberglass Stainless Steel Water Treatment Plant Ro System

Product Description

500L/H 1000L/H Fiberglass Stainless Steel Water Treatment Plant Ro System

RO Water Treatment Reverse Osmosis System

Reverse osmosis (RO) is a kind of water purification technology that uses a semipermeable membraneunder pressure applied to remove ions, molecules, and larger particles , bactaria and so on from water, and is used in both industrial processes and the production of potable water.

Typical Reverse Osmosis Processing:

Raw water pump → Silica sand filter → Activated carbon filter→ Sodium ion exchanger → Security filter → High-pressure pump → Reverse osmosis system →Uv sterilizer→Ozone sterilizer →Finished Water tank

1. Raw water pump: provide the pressure to silica sandfilter/active carbon filter

2. Silica Sand filter: get rid of turbidity, suspended matter, organic matter, colloid and so on

3. Activated Carbon filter: Remove the color, free chloride, organic matter, harmful matter and so on

4, WATER Softener: Get rid of calcium and magnesium ions in original / source water, reduce water hardness.

5. Security filter: prevent any deposition of large Particles, most of the bacteria, and viruses into the RO membrane, The accuracy is 5um, for holding back any large particulates such as large iron, dust, suspended matter, impurity.

6. High pressure pump-- Provide the high pressure to RO membrane(at least 2.0 Mpa).

7. RO system-- main part of pure water treatment plant. The desaltation rate upto 99%, it is capable of removing over 99% of ions, bacterias, particles and 98% of organic.

8.UV sterilizer -- kill some bacteria that may also pass through the reverse osmosis

9.Ozone sterilizer -- Use ozone Kill bacteria not killed by UV 10.Finished water tank -- For filter water storage
